Cisco IR1101 Manual

Memory
The Cisco IR1101 uses flash memory and main memory. The flash memory contains the Cisco OS software
image and the boot flash contains the ROMMON boot code. The memory includes:
• 4 GB DRAM (soldered down)
• 4 GB onboard flash memory
Reset Button
The Reset button resets the router configuration to the default configuration set by the factory. To restore the
router configuration to the default configuration set by the factory, use a standard size #1 paper clip with wire
gauge 0.033 inch or smaller and simultaneously press the reset button while applying power to the router.
Supported Cisco Antennas and Antenna Accessories
The IR1101 must have a Pluggable Module with antenna ports installed in order to connect antennas. The
base unit does not have any wireless capabilities on its own.
The Antenna Selection and Installation chapter lists the supported Antennas and Accessories for the Cisco
IR1101 with a wireless Pluggable Module. For detailed information about Cisco Antennas for the Industrial
Routers, please refer to the following guide:
Cisco Industrial Routers and Industrial Wireless Access Points Antenna Guide:
http://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing-combined/industrial-routers-and-industrial-wireless-antenna-guide.html
Modem Support
The Cisco IR1101 wireless Pluggable Module uses the Sierra Wireless series modems. The software download
page can be found here:
https://software.cisco.com/download/navigator.html?mdfid=286288566&flowid=76082
Table 8 and Table 9 shows the technology details for the modems.
Table 8: Modem Technology Supported
Technology SupportedDescriptionModem UsedSKU ID
LTE CAT4: B4, B13U.S. (Verizon) Single
Micro SIM
WP7601-GP-LTE-VZ
LTE CAT4:B2,B4,B5,B12
3G UMTS DC-HSPA+, HSPA+, HSPA,
WCDMA: B2,B4, B5
North America (AT&T)
Dual Micro SIM
WP7603-GP-LTE-US
LTE CAT4: B1, B3, B8, B11, B18, B19, B21
3G UMTS HSPA+
JapanWP7605-GP-LTE-JN
Product Overview
14
Product Overview
Memory

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
