Cisco IR1101 Getting Started

2
Getting Started and Product Document of Compliance for the Cisco IR1101 Industrial Integrated Services Router
The following items are shipped with your router:
 This document
 Power Connector
 Grounding Lug Kit
Equipment that you supply
 ESD-preventive cord and wrist strap.
 Wire-stripping tools for stripping 14- and 18-gauge wires
 Crimping tool
 Ratcheting torque screwdriver that exerts up to 15 in-lb (1.69 N-m) of pressure.
Related Documentation
To access resources or to display the latest Cisco 1101 Series Router documentation on-line, go to this URL:
https://www.cisco.com/c/en/us/support/routers/1101-industrial-integrated-services-router/model.html
This portal has all of the information you need to get to know your router, install and configure it, as well as access
software. You will see the following categories as well as other important information:
 All support information for Cisco IR1101 Series Industrial Integrated Services Routers: Provides the most
requested resources and a list of all of the models in the series.
 Release and General Information: Links to the Software Download site, Compatibility Information, Licensing
Information, and Product Release notes.
 Install and Upgrade: This is your starting point for Installing the Router. look under The Install and Upgrade Guide
section for this model,
 Configure: These links provide configuration information. Look first under the Configuration Guide section for this
model.
Other important and helpful links to Cisco information are here:
 Cisco.com: www.cisco.com
 Warranty and EULA Information: https://www.cisco.com/c/en/us/products/warranty-listing.html
 Cisco Marketplace: www.cisco.com/pcgi-bin/marketplace/welcome.pl
 Cisco Product Documentation: www.cisco.com/go/techdocs
 Cisco Support: www.cisco.com/cisco/web/support/index.html
Installation Warning and Caution Statements for Hazardous Locations
Environments
Warning: IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any
equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for
preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the
translated safety warnings that accompanied this device. Statement 1071

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
