Cisco Nexus 3000 series Hardware Installation Guide

Overview of the Cisco Nexus 31128PQ Switch
The Cisco Nexus 31128PQ (N3K-C31128PQ-10GE) is a 2 rack unit (RU) switch with 96 fixed 10-Gbps
enhanced small form-factor pluggable (SFP+) ports and 8 fixed 40-Gbps quad small form-factor pluggable
(QSFP+) ports, 1 management port, 1 console port, and 2 USB ports. This switch supports both port-side
exhaust and port-side intake airflow schemes. The switch requires one AC or DC power supply for operations,
but it can have a second power supply for redundancy.
The following figure shows the fan-side chassis features that you use when installing the chassis or replacing
its modules.
Figure 22: Fan-Side View of the Cisco Nexus 31128PQ Chassis
Fan modules (2)3Grounding pad1
Beacon (BCN) and Status
(STS) LEDs
4Power supply modules (2)2
The following figure shows the port-side chassis features that you use when installing the chassis or replacing
its modules.
Cisco Nexus 3000 Series Hardware Installation Guide
23
Overview
Overview of the Cisco Nexus 31128PQ Switch

Cisco Nexus 3000 series Specifications

General

Category	Switch
Latency	Sub-microsecond
Typical Power Consumption	Varies by model
Layer	L2/L3
Management	CLI, SNMP
Port Density	Varies by model
Forwarding Capacity	Up to 2.4 Bpps
