Cisco UCS C22 M3 User Manual

Cisco UCS C22 M3 High-Density SFF Rack-Mount Server
CONFIGURING the SERVER
15
STEP 4 SELECT RAID CONFIGURATION
The RAID controller choices are:
■ Software RAID, implemented using the C600 chipset built-in SAS RAID controller plus LSI
MegaSR (this configuration does not consume a PCIe slot), or
■ Plug-in PCIe controller cards:
— LSI MegaRAID 9265CV-8i (with 1 GB TMM data cache and SuperCap for data cache
power backup)
— LSI MegaRAID 9240-8i
— LSI MegaRAID 9220-8i
— LSI MegaRAID 9220-4i
Cisco can provide factory-configured RAID systems depending on the RAID controller card chosen
and the number of drives ordered. Factory-configured RAID options are listed in
Table 5.
RAID levels 50 and 60 are supported, although they are not available as factory-configured RAID
options.
Select RAID Options
Select one RAID controller (either software RAID in Tabl e 5 or hardware RAID using a plug-in
RAID controller and an appropriate RAID configuration option in Table 6 on page 16).
NOTE: Factory-configured RAID is not available if you choose software RAID (in this
case, you must configure RAID yourself using separate software).
Table 5 Available Software RAID (LSI MegaSR) Options
Product ID (PID) PID Description
RAID Controllers
UCSC-RAID-ROM5 Software RAID (LSI MegaSR), supporting up to eight SAS or SATA drives. SAS and
SATA drives can be mixed. This option supports RAID 0, 1, and 10, and operates
at 3 Gb/s. Operating systems supported are Windows and Linux only (no VMware
support).
UCSC-RAID-ROM55 Software RAID (LSI MegaSR), supporting up to eight SAS or SATA drives. SAS and
SATA drives can be mixed. This option supports RAID 0, 1, 10, and 5, and
operates at 3 Gb/s. Operating systems supported are Windows and Linux only
(no VMware support).
