Cisco UCS C220 M3 Quick Start Guide

2
Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
78-21007-01
Product Description
Recovery Media and Recovery Procedure, page 10
If You Need to Return Your Bundle to Cisco, page 11
Related Documentation, page 11
Product Description
This printed copy of Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide (“Quick Start
Guide”) is provided with shipments of Cisco Security Manager 4.3 UCS Server Bundles. This “Quick
Start Guide” is also available on Cisco.com at the following URL:
http://www.cisco.com/en/US/products/ps6498/prod_installation_guides_list.html.
Cisco Security Manager 4.3 UCS Server Bundles (“Bundle”) is a software and hardware bundle that was
developed by Cisco Systems, Inc., for users of Cisco Security Manager. Cisco did the following things
to develop this Bundle:
1. Selected a server, the Cisco UCS C220 M3, and configured it with appropriate HDDs, RAM, and
other components (this was done by Cisco before shipment of the Bundle to you).
The Cisco UCS C220 M3 is a rack server in a 1RU form factor. You can see an interactive model of
it at the following URL:
http://www.cisco.com/en/US/prod/collateral/ps10265/ps10493/ps12369/ucs_c220_kaon_model_pr
eso.html.
Note Two hardware configurations are available for this Bundle. However, this “Quick Start Guide”
(and all the documentation referred to in it) applies to both of the available hardware
configurations. The two hardware configurations are low-end (16 GB RAM, 4 x 500 GB HDD)
and high-end (24 GB RAM, 7 x 500 GB HDD).
2. Set up the BIOS on the Cisco UCS server (this was done by Cisco before shipment of the Bundle to
you).
3. Installed the operating system, Microsoft Windows Server 2008 R2 SP1 Enterprise (64-bit) (“the
OS”) (this was done by Cisco before shipment of the Bundle to you).
4. Tuned the OS (this was done by Cisco before shipment of the Bundle to you).
5. Installed Common Services 4.0, which provides the framework for installation, user role definitions,
and many other functions (this was done by Cisco before shipment of the Bundle to you).
6. Installed Cisco Security Manager 4.3 (“Security Manager”) (this was done by Cisco before shipment
of the Bundle to you).
7. Tuned Security Manager (this was done by Cisco before shipment of the Bundle to you).
The next steps—unpacking the shipping carton, obtaining an IP address, securing the Security Manager
credentials, and all the rest—are to be taken by you as (1) the admin user of Security Manager and (2)
the administrator of the Cisco UCS Server.
Cisco recommends that you read this “Quick Start Guide” and the other documentation that you will find
packed in your shipping carton along with your new Bundle itself, especially the poster (“Cisco UCS
C220 Server Quick Start Guide,” Cisco 78-20790-02).
Also, please be sure to refer to the “Related Documentation” section of this “Quick Start Guide.”
Please be aware of the following information regarding this product:

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
