Cisco UCS C220 M3 Quick Start Guide

6
Cisco Security Manager 4.3 UCS Server Bundles Quick Start Guide
78-21007-01
Updates and Service Packs for Windows
The high-end hardware configuration (24 GB RAM, 7 x 500 GB HDD) provides support for 150 devices.
This configuration is suitable for a medium enterprise deployment. The maximum number (cumulative)
of events per second supported is 10,000 events per second [this value is a 9:1 ratio of syslogs to IPS
SDEE (i.e., 9000 syslog + 1000 SDEE)].
Note Cisco does not recommend (1) attempting to expand the capabilities of the high-end hardware
configuration (24 GB RAM, 7 x 500 GB HDD) by adding licenses or hardware or (2) otherwise
attempting to change the license configuration or hardware or both; the Bundle was tested as shipped.
Updates and Service Packs for Windows
Your new Bundle was shipped to you with current Windows updates installed.
Also, Windows Update was set to “Check for updates but let me choose whether to download and install
them.”
Tip To change the Windows Update setting, select Control Panel > System and Security > Windows
Update > Let me Choose My Settings.
As the administrator of the Cisco UCS Server which forms part of this Bundle, you are responsible for
the necessary updates and service packs for Windows. Cisco does not provide Windows updates or
service packs.
Patches and Service Packs for Security Manager
Your new Bundle was shipped to you with current Cisco Security Manager patches and service packs
installed.
Note Service Pack 1 for Security Manager 4.3 is pre-installed in your new Bundle.
As the admin user of Security Manager installed on this Bundle, you are responsible for the necessary
patches and service packs for Security Manager. Cisco does not install them for you or notify you.
If you have a valid Cisco Service contract, you will be able to upgrade the Cisco Security Manager
software from Version 4.3 to a future version.
Usernames and Passwords
Windows:
• Default Windows username/password: Administrator/cisco@123
• To change the Windows username/password: Follow the procedures published by Microsoft for
Windows Server 2008.
Security Manager admin:
• Default Security Manager admin username/password: admin/cisco@123

Cisco UCS C220 M3 Specifications

General

Tcase	70 °C
Bus type	QPI
Stepping	M1
FSB Parity	No
Scalability	2S
Processor cache	10 MB
Processor cores	4
System bus rate	6.4 GT/s
Processor series	Intel Xeon E5-2600
Processor socket	LGA 2011 (Socket R)
Processor codename	Sandy Bridge EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	52.5 x 45.0 mm
Processor front side bus	- MHz
Processor boost frequency	2.50 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Graphics & IMC lithography	32 nm
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	24
Physical Address Extension (PAE)	46 bit
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	750 GB
HDD size	2.5 \
HDD interface	-
Total storage capacity	500 GB
Compatible memory cards	SD
Maximum storage capacity	- TB
Memory slots	16
Internal memory	32 GB
Memory clock speed	1866 MHz
Maximum internal memory	- GB
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Chassis type	Rack (1U)
Power supply	450 W
Safety	UL 60950-1 No. 21CFR1040, CAN/CSA-C22.2 No. 60950-1, IEC 60950-1, EN 60950-1, IEC 60950-1, AS/NZS 60950-1, GB4943 2001
Certification	47CFR Part 15 (CFR 47), AS/NZS CISPR22, CISPR2 2, EN55022, ICES003, VCCI, EN61000-3-2, EN61000-3-3, KN22, CNS13438, EN55024, CISPR24, EN300386, KN24
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 12000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 90 %
PCI Express slots version	3.0
Processor ARK ID	64588
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	724 mm
Width	430 mm
Height	43.2 mm
