Dimensions
Table 6 provides Catalyst 6500 Series chassis dimensions.
Weight
Table 7 provides the weight information for empty and fully configured Catalyst 6500 Series chassis.
ORDERING INFORMATION
Table 8 provides part number information for Catalyst 6500 Series chassis.
Table 6 Catalyst 6500 Series Chassis Dimensions
Dimension
Cisco
Catalyst
6503
Cisco
Catalyst
6506
Cisco
Catalyst
6509
Cisco
Catalyst
6509-NEB
Cisco
Catalyst
6509-NEB-A
Cisco
Catalyst
6513
H x W x D (in.) 7 x 17.37 x
21.75 in.
20.1 x 17.2 x
18.1 in.
25.2 x 17.2 x
18.1 in.
33.3 x 17.2 x
18.1 in.
36.65 x 17.20 x
20.32 in.
33.3 x 17.3 x
18.1 in.
H x W x D
(cm)
17.8 x 44.1 x
55.2 cm
51.1 x 43.7 x
46.0 cm
64.0 x 43.7 x
46.0 cm
84.6 x 43.7 x
46.0 cm
93.09 x 43.68
x 51.61 cm
84.6 x 43.7 x
46.0 cm
Rack units
(RU); 1.75 in.,
4.4 cm
4 RU 12 RU 15 RU 20 RU 21 RU 20 RU
Table 7 Catalyst 6500 Series Chassis Weights
Weight
Cisco
Catalyst
6503
Cisco
Catalyst
6506
Cisco
Catalyst
6509
Cisco
Catalyst
6509-NEB
Cisco
Catalyst
6509-NEB-A
Cisco
Catalyst
6513
Chassis only
(lb)
27 lb 45 lb 55 lb 55 lb 121 lb 98 lb
Fully
configured
(lb)
85.4 lb 156.6 lb 194.5 lb 194.5 lb 270 lb 280 lb
Chassis only
(kg)
12.25 kg 20.41 kg 24.9 kg 24.9 kg 54.88 kg 45 kg
Fully
configured
(kg)
38.8 kg 71.2 kg 88.4 kg 88.4 kg 122.47 kg 127.3 kg
Table 8 Catalyst 6500 Series Chassis Part Numbers
Part Number Chassis
WS-C6503 Cisco Catalyst 6503 chassis (three slots)
WS-C6506 Cisco Catalyst 6506 chassis (six slots)
WS-C6509 Cisco Catalyst 6509 chassis (nine slots)
