Arion 500-600 10.07 –
GB
A.15
AIR CONDITIONING
SAFETY CABS
The air conditioning system contains a gas which can be
dangerous under certain conditions.
RECOMMANDATIONS :
RECOMMENDATIONS:
Ne jamais intervenir sur l e circuit defrigération
Never work on the air conditioning.
If a leak occurs, prevent any concentration of the gas (in a
closed building, in the cab, etc.). Avoid any contact between
the gas and hot articles. Do not smoke.
CONSEI L
IMPORTANT
It is recommended to keep a fire extinguisher and a first-aid kit
ready to hand.
001hsn38
Our safety cabs have successfully undergone the official E.E.C.
and O.E.C.D. tests. As a result of these tests they have been
officially approved. They fully satisfy these tests.
Consequently, CLAAS disclaims responsibility for any accident
(impact or overturning) which applies loads greater than those
required by the tests to the structure.
Any safety structure which has been damaged (distorted) in an
accident must be replaced, not repaired.
If you want to add equipment or functions not provided as
standard or available as after-sales options, always contact
your CLAAS agent. It is important to obtain his advice since it is
forbidden to drill, weld or cut any of the safety structure
components since this would change the cab characteristics
and it would then no longer have official approval.
001hsn17

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Claas ARION 540 and is the answer not in the manual?

Claas ARION 540 Specifications

General IconGeneral
Max Speed40 km/h
Hydraulic SystemOpen Center
Max. lift capacity6200 kg
Lift Capacity6200 kg
Engine Power134 hp
TransmissionHexashift
Rated Power107 kW
Max. Power145 HP
Number of gears24 forward / 24 reverse
Hydraulic pump flow110 L/min
Weight5200 kg
Engine Type4-cylinder
Hydraulic Pump Capacity110 L/min
Engine4-cylinder, Turbocharged
