13
CZ202E/CZ202ER/CZ202EG
right part.
2. Push the trim ring to left and pull out the
left part.
Disassemble the unit
1. Switch off the power.
2. Remove the panel.
3. Remove the trim ring.
4. Insert the removal keys straight back until
they lock, then pull the unit out.
5. Disconnect all the wires.
Method B
6) Removing the Source Unit
Mounting Frame
Dashboard
M5x6
1. Insert this unit directly to the opening of
the dashboard.
2. Place M5×6 cylindrical screw through the
holes of the mounting frame located inside
the opening to holes of the unit and fasten
the screws to left & right.
Trim Ring Installation
Attach the trim ring around the front panel.
Disassemble trim ring
1. Push the trim ring to right and pull out the
Top
Bottom
7) Wiring and Connections
Rear Right / SUB OUT 2
Rear Left / SUB OUT 1
SWC
Refer to next page
Rear audio output (Left)/
White
Red
4 Channel Amplier
Antenna
Black
Black
Black
Black
(Black)
Rear audio output (Right)/
Steering wheel
control terminal
Subwoofer output 1
Subwoofer output 2
White
Gray
Red
Left
Right
Front audio
output terminal
C
9
10
11
12
13
14
15
16
1
2
3
4
5
6
7
8
A
B
2
4
6
8
1
3
5
7
1
3
5
7
2
4
6
8
