7) Wiring and Connections
USB connector
Black
SAT BUS
SAT L (White)
White
Black
Red
Black
White
Gray
Red
Left
Right
Front audio
output terminal
4-channel amplier
Rear audio output (Left)
Subwoofer output 1
Rear audio output (Right)
Subwoofer output 2
(Black)
ANTENNA
Refer to the next page.
HD BUS
SAT R (Red)
(Black)
(Black)
HD RADIO
XM
RADIO
CCUXM1
CNP2000UC
THD300
