Clarion DB265MP Service Manual

-9-
DB265MP/DB266MP
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1
----------- SENSOR PWB 1 38 621-1749-20 POWER GEAR B
1
2 966-1743-21 DRIVE-PLT-ASSY
1
39 621-1750-20 POWER GEAR C
1
3
SMA-182-100
SPINDLE MOTOR-ASSY
1
40 621-1751-20 POWER GEAR D
1
4
SMA-183-100
SLED MOTOR-ASSY
1
41 621-1752-20 DISC STOPPER
1
5 345-5476-20 CUSHION RUBBER
1
42 621-1753-20 CLAMPER RING
1
6 620-1023-23 CLAMPER PLATE
1
43 621-1754-20 GEAR BASE
1
7 620-1026-21 SPRING PLATE
1
44 622-1571-21 ROLLER SHAFT
1
8 620-1596-23 CLAMPER LINK
1
45 624-0020-00 LEAD SCREW
1
9 620-1598-22 UPPER CHASSIS
1
46 629-0086-20 DAMPER F
2
10 620-1752-20 SENSOR ARM
1
47 629-0087-20 DAMPER R
1
11 620-1753-20 ID-LOCK PLATE
1
48 716-1507-01 SCREW(M2x3)
1
12 620-1748-21 LOWER CHASSIS
1
49 716-1670-01 SCREW(M2x4)
4
13 621-0608-21 SECOND GEAR
1
50 716-1733-01 SCREW(M1.7x2.3)
2
14 621-0609-20 BASE GEAR
1
51 716-3469-01 SCREW(1.7x4)
2
15 621-0610-20 IDLE GEAR A
1
52 716-3473-01 SCREW(M2x3)
1
16 621-0611-20 IDLE GEAR B
1
53 716-3551-00 SCREW(M1.4x2.5)
2
17 621-0612-21 ROLLER GEAR A
1
54 750-3467-21 SHIFT SPRING
1
18 621-0620-20 THREAD GEAR A
1
55 750-3468-20 RACK SPRING
1
19 621-0621-20 THREAD GEAR B
1
56 750-3469-20 CLAMPER SPRING
1
20 621-0623-23 LS-HOLDER
1
57 750-3470-20 ID-LOCK SPRING
1
21 621-0624-22 GUIDE RAIL
1
58 750-3471-20 SENSOR SPRING
1
22 621-0711-20 LOADING ROLLER
2
59 750-3472-21 DR-SPRING F
2
23 621-0718-21 ROLLER GUIDE
1
60 750-3473-20 DR-SPRING RA
1
24 621-0719-20 ROLLER GEAR
1
61 750-3474-20 DR-SPRING RB
1
25 621-0720-20 ROLLER GEAR C
1
62 750-3475-21 DR-SPRING C
1
26 621-0721-20 ROLLER GEAR D
1
63 750-6797-20 ROLLER SPRING L
1
27 621-0728-20 STOPPER LINK
1
64 750-6798-20 ROLLER SPRING R
1
28 621-1719-20 IDLE CASE
1
65 714-2003-8B SCREW(M2x3)
2
29 621-1726-20 ROLLER SLEEVE
2
66 780-2025-00 SCREW(M2x2.5)
3
30 621-1729-20 SH-BASE
1
67 781-1730-00 SCREW(M1.7x3)
1
31 621-1742-20 UPPER GUIDE
1
68 803-4906-60 VINYL-COAT-WIRE(ORG)
1
32 621-1743-20 SHIFT LEVER
1
69 969-0071-30 PICKUP-ASSY
1
33 621-1744-20 RACK
1
70 816-2590-00 LEAD(GRN)
1
34 621-1745-20 LOCK ARM L
1
71 816-2591-00 LEAD(YEL)
1
35 621-1746-20 LOCK ARM R
1
72 816-2592-00 LEAD(BLUE)
1
36 621-1747-20 GEAR COVER
1
73 816-2593-00 LEAD(PUR)
1
37 621-1748-20 POWER GEAR A
1
74 966-1722-20 SH-RACK-ASSY
1
ELECTRICAL PARTS LIST
Main PWB (B1) section
Note)Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
REF No.
PART No.
DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT1 092-4000-51 ANT-RECEPT C29 187-1073-25 10V 100uF C107 166-4711-50 470pF
BL1
880-2090B
TUNER C30 187-4763-35 16V 47uF C108 178-4742-78 0.47uF
C1 166-2201-50 22pF CH C31 168-5622-55 5600uF C109 178-4742-78 0.47uF
C2 166-2201-50 22pF CH C32 166-1007-50 10pF C110 178-4742-78 0.47uF
C3 168-1022-55 1000uF C33 168-1032-55 0.01uF C111 178-4742-78 0.47uF
C4 168-4732-78 0.047uF C37 168-1042-78 0.1uF C113 187-1063-35 16V 10uF
C6 168-1032-55 0.01uF C38 187-1053-65 50V 1uF C114 178-2242-78 0.22uF
C9 187-4763-35 16V 47uF C45 187-4763-15 6.3V 47uF C115 168-1042-78 0.1uF
C11 168-1032-55 0.01uF C47 166-1011-50 100pF C116 187-1053-65 50V 1uF
C15 187-1053-65 50V 1uF C48 166-1011-50 100pF C117 172-2231-15 0.022uF
C19 168-1832-55 0.018uF C52 166-1501-50 15pF CH C118 042-1447-00 16V 2200uF
C20 168-2232-55 0.022uF C53 166-1801-50 18pF CH C119 168-1022-55 1000pF
C21 168-2232-55 0.022uF C54 168-4722-55 4700pF C124 168-1042-78 0.1uF
C22 166-1007-50 10pF C100 166-4711-50 470pF C125 168-1022-55 1000pF
C23 168-1522-55 1500uF C101 166-4711-50 470pF C500 187-1063-35 16V 10uF
C24 187-1073-25 10V uF C102 166-4711-50 470pF C504 187-1063-35 16V 10uF
C25 168-1042-78 0.1uF C103 166-4711-50 470pF C506 187-2253-65 50V 2.2uF
C26 168-1032-55 0.01uF C104 166-4711-50 470pF C507 166-1011-50 100pF
C27 168-6822-55 6800pF C105 166-4711-50 470pF C508 166-1011-50 100pF
C28 166-1011-50 100pF C106 166-4711-50 470pF C509 166-1011-50 100pF
