18 DB265MP
280-8303-00
English
11. SPECIFICATIONS
FM tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 11 dBf
50 dB Quieting Sensitivity: 17 dBf
Alternate Channel Selectivity: 75 dB
Stereo Separation (1 kHz): 35 dB
Frequency Response (±3 dB): 30 Hz to 15 kHz
AM tuner
Frequency Range:
AM: 530 kHz to 1710 kHz
Usable Sensitivity: 25 µV
CD player
System: Compact disc audio system
Usable Discs: Compact disc
Frequency Response: 10 Hz to 20 kHz (±1 dB)
Dynamic Range: 95 dB (1 kHz)
Harmonic Distortion: 0.01%
MP3
Decode Format: MPEG 1, 2 and 2.5 -Layer 3
Sampling rate (kHz):
MPEG-1: 32, 44.1, 48
MPEG-2: 16, 22.05, 24
MPEG-2.5: 11.025, 12
Bit-rate (kbps):
8, 16, 24, 32, 40, 48, 56, 64, 80, 96, 112, 128,
144, 160, 192, 224, 256, 320, VBR
CD-ROM Format:
ISO9660 level 1, 2, Joliet or Romeo
Folder Level Limit: No limitation
Folder Support: 128
File Support: 254
Folder Name: Maximum 16 characters
File Name: Maximum 28 characters
Audio
Maximum Power Output: 180 W (45 W × 4 ch)
Bass Control Action (100 Hz): ±14 dB
Treble Control Action (10 kHz): ±14 dB
Line Output (with A/C 1 kHz, 10 k Ω): 1.8 V
General
Power Supply Voltage:
14.4 V DC (10.8 V to 15.6 V allowable),
negative ground
Current Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 Ω to 8 Ω allowable)
Weight: 2.42 lb. (1.1 kg)
Dimensions:
178 mm Width × 50 mm Height × 152 mm
Depth
Power Output :
19 W RMS x 4 Channels at 4 Ω
and 1 % THD+N
Signal to Noise Ratio:
80 dBA (reference: 1 W into 4 Ω)
50 mm178 mm
58 mm188 mm
152 mm
Notes:
• Specifications and design are subject to change
without notice for further improvement.
• Please make sure when connecting external
power amplifier, that you properly, to the car
chassis, ground the amplifier.
• If this is not done, severe damage to the source
unit may happen.
