Clarion DB568RUSB User Manual

14
English
DB568RUSB
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step Tuning mode, the fre
-
quency changes one step at a time. In the quick
Tuning mode, you can quickly tune the desired
frequency.
1. Press the
[
BND
]
button and select the desired
band
(
FM or AM
(
MW/LW
))
.
∗ If “MANU” is not lit in the display, press and hold
the
[
BND
]
button for 1 second or longer.
“
MANU” is lit in the display and manual tuning
is now available.
2. Tune into a station.
Quick tuning:
Press and hold the
[
,
]
button for 1 second
or longer to begin station tuning.
Radio Mode Operations
Listening to the radio
1. Press the
[
SRC
]
button and select the Radio
mode, then the radio will be on.
2. To select a preset band, press the
[
BND
]
but-
ton, then select one of the preset bands such
as FM1, FM2, FM3 or AM
(
MW/LW
)
. Every
time the
[
BND
]
button is pressed, the display
will change as:
FM1 FM2 FM3 AM
(
MW/LW
)
FM1...
3. Press the
[
,
]
button to tune in the
desired station.
Seek tuning
There are 2 types of seek tuning: DX SEEK and
LOCAL SEEK.
DX SEEK can automatically tune in to receivable
broadcast stations; LOCAL SEEK can tune in to
only broadcast stations with a good reception
sensitivity.
1. Press the
[
BND
]
button and select the desired
band
(
FM or AM
(
MW/LW
))
.
∗ If “MANU” is lit in the display, press and hold
the
[
BND
]
button for 1 second or longer.
“
MANU” in the display goes off and seek tuning
is now available.
∗ If “TA” is lit in the display, TP stations are auto-
matically sought.
2. Press the
[
,
]
button to start automatic
station tuning.
DX SEEK
When the
[ ]
button is pressed, search will be
performing in the direction of higher frequencies.
When the
[ ]
button is pressed, search will be
performed in the direction of lower frequencies.
∗ When seek tuning starts, “DX” appears in the
display.
Step tuning:
Press the
[
,
]
button to perform manual
tuning.
∗ If no operation is performed for more than 7 sec-
onds, manual tuning is cancelled and the display
returns to the previous mode.
Manual memory function
1. Press the
[
BND
]
button, to select a band you
want to store in the memory.
2. Press the
[
,
]
button to tune into a desired
station.
3. Press and hold one of the
[
DIRECT
]
buttons for
2 seconds or longer to store the current station
into preset memory.
Preset memory function
Preset memory function can store up to 24 sta-
tions:
Six stations for each of FM1, FM2, FM3 and AM
(
MW/LW
)
.
LOCAL SEEK
If the button is pressed and held in position for
1 second or longer, local seek tuning will be en-
abled. Broadcast stations with good reception
sensitivity are selected.
∗ When local seeking starts, “LO” appears in the
display.

Clarion DB568RUSB Specifications

General

Brand	Clarion
Model	DB568RUSB
Category	Car Receiver
Language	English
