Parts List and Exploded view - Pump
No. Qty Description Part No
1 1 Pump body GM5120
2 1 Support GM7033
3 1 Impeller GM7479
4 1 Gasket GM5129
5 1 Counterface GM6344
6 1 Mechanical Seal GM6332
7 1 Valve body GM7039
8 1 Rivet GM5133
9 1 Valve gasket GM5128
10 1 Washer GM6168
11 1 O ring GM5326
12 1 Plug 3/8” GM6217
13 1 Plug 1/8” GM6208
14 1 O ring GM5127
15 1 Diffusor GM7025
16 2 Connection GM1011
17 1 Bush GM5125
18 Complete motor GM8104
(with B53 recoil starter)
18 Complete motor GM7381
(with standard recoil starter)
For Spare Parts and Service, please contact your nearest dealer, or
CLARKE International, on one of the following numbers.
PARTS & SERVICE TEL: 020 8988 7400
PARTS & SERVICE FAX: 020 8558 3622
or e-mail as follows:
PARTS: Parts@clarkeinternational.com
SERVICE: Service@clarkeinternational.com
Spare Parts and Service Contacts
10
