No.Qty Description Part No
1 4 Screw M5 x 25 GM7306
2 1 Cover (std recoil starter) GMB219
2A 1 Cover (B53 recoil starter)GMB387
3 1 Stop button GMB191
4 1 Button spring GMB190
5 1 Circlip GMB207
6 2 Screw M4 x 15 GM7308
7 2 Washer GM7570
8 1 Flywheel GMB133
9 1 Coil GMB132
10 4 Screw M5 x 20 GM7319
11 4 Washer GMA661
12 1 Carburettor GMB135
13 1 Inlet duct GMB244
14 1 Duct gasket GMB241
15 1 Diaphragm plate GMB243
16 1 Inlet diaphragm GMB240
17 1 Diaphragm plate GMB239
18 1 Duct gasket GMB241
19 1 Fuel pipe GMA611
20 1 Fuel cock GMB148
21 1 Nut GMB333
22 1 Washer MB334
23 1 Tank gasket GM7222
24 1 Fuel tank GM7605
25 1 Fuel filler cap GM7611
26 4 Washer GM6157
27 4 Gasket GM7604
28 4 Nut M6 GM6276
29 1 Seal ring GMA338
30 2 Tie rod GMB237
31 1 Cylinder gasket GMB186
32 1 Crankcase GMB299
33 2 Bush GMB290
34 1 Bearing GMA656
35 1 Cylinder shaft GMB362
35A 1 Conical shaft GMB221
36 1 Bush GMB323
37 1 Con rod assembly GMB152
38 1 Piston pin GMB146
39 2 Circlip GMB147
40 1 Piston GMB144
41 2 Piston ring GMB145
42 1 Cylinder GMB249
43 1 Head gasket GMB185
44 1 Cylinder head GMB160
45 4 Nut M6 GM6304
46 1 Spark plug GMB253
47 2 Washer GM6156
48 2 Screw M6 GMA699
49 1 Gasket GMB189
50 6 Nut M4 GM6719
51 1 Key GMB242
52 1 Bearing GMA656
53 1 Silencer gasket GMB188
54 1 Gasket GMB187
55 1 Silencer GMB168
56 2 Tie rod GMB237
57 6 Screw M4 x 25 GM7307
58 1 Crankcase GMB223
59 4 Screw M5 x 40 GM7305
60 1 Seal ring GMA338
61 1 Silencer cover GMB369
62 4 Rubber foot GMA576
63 1 Engine support GM5318
64 4 Screw GMA691
65 4 Washer GM6156
66 1 Insert (B53 recoil starter) GMB388
67 1 Nut (B53 recoil starter) GMB386
Gasket set GMB366
(Items 23, 29, 31, 43, 53, 54)
Complete piston GMB381
(Items 38, 39, 40, 41)
Complete cylinder GMB355
(Items 38, 39, 40, 41, 42)
Parts List and Exploded view - Engine
