Clevo N550RN User Manual

Disassembly
2 - 6 Removing the Battery
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Remove the SD card cover and screws - (Figure 2a).
3. Carefully lift the bottom case
up from point and remove it (Figure 2b).
4. The battery will be visible at point on the computer (Figure 2c
).
6
1
2
15
16
17
18
Figure 2
Battery Removal
a. Remove the SD cover
and screws.
b. Remove the bottom case.
c. Locate the battery.
2
a.
b.
1
3
4
5
16
13
18
6
7
17
89
11
12
14
15
10
c.
16
17

1. SD Card Cover
16. Bottom Case
•14 Screws
