Clint MultiPower CHA/K 1208-P User Manual

13
R410A
(1) Referential conditions at page 6.
TECHNICAL DATA
16812-P 18012-P 21012-P 24012-P 27012-P 30012-P 33012-P 36012-P MODEL
Refrigerant cycle:
536 590 665 738 827 920 1014 1102
Cooling Capacity (1)
179 199 230 266 305 340 368 412
Absorbed power (1)
Free-cooling cycle:
-2,2 -2,7 -3,0 -3,5 -2,5 -0,1 0,1 -0,4
Heating capacity (1)
17,5 17,5 17,5 21,0 24,5 28,0 31,5 31,5
Absorbed power (1)
6 + 6 6 + 6 6 + 6 6 + 6 6 + 6 6 + 6 6 + 6 6 + 6
Compressors:
2 2 2 2 2 2 2 2
Refrigerant Circuits
8 8 8 8 8 8 8 8
Capacity steps
Water circuits:
28,28 31,09 35,11 38,89 43,64 48,52 53,51 58,13
Water/glycol ow (1)
121 132 148 152 172 151 162 173
Pressure drops (1)
125 125 125 150 150 150 150 150
Water connections
340 340 400 410 490 720 810 810
Water/glycol volume (1)
Compressors
6x12,1+6x14,8 12,0x15,1 6x20,5+6x14,9 12x20,4 6x20,6+6x26,1 12x26,0 6x25,3+6x30,8 12x31,7
Unitary absorbed power (1)
6x20,7+6x25,9 12,0x26,4 6x35,3+6x26,0 12x35,2 6x34,6+6x45,9 12x45,6 6x44,8+6x51,3 12x52,6
Unitary absorbed current (1)
3,3-3,6 3,6 6,7 6,7 6,7 6,7 6,7-7,2 7,2
Oil charge
Standard version and with SL accessory:
42,2 42,2 45,6 50,6 61,7 67,8 76,1 76,1
Airow
10 10 10 12 14 16 18 18
Fans
17,5 17,5 17,5 21,0 24,5 28,0 31,5 31,5
Nominal power - fans
37 37 37 45 52 60 67 67
Nominal current - fans
84 84 87 88 88 89 89 90
Sound pressure level DIN (1)
80 80 83 85 85 85 85 86
Sound pressure level with SL accessory DIN (1)
71 71 74 75 75 75 75 76
Sound pressure level ISO (1)
67 68 70 71 71 71 71 72
Sound pressure level with SL accessory ISO (1)
2x52 2x52 2x58 2x62 2x63 2x65 2x70 2x70
Refrigerant charge R410A
6200 6200 7200 7200 8400 9600 10600 10600
Lenght
2200 2200 2200 2200 2200 2200 2200 2200
Width
2360 2360 2360 2360 2360 2360 2360 2360
Height
4180 4220 5060 5240 5830 6880 7410 7530
Transport weight
4240 4280 5120 5300 5900 6950 7490 7610
Transport weight with SL accesory
Total electrical consumption:
<----------------------------------------------- 400/3/50 ----------------------------------------------->
Power supply
371 397 466 530 607 683 733 776
Max. Current
538 564 640 705 815 891 994 1037
Starting current
