Coleman CT200U-A User Manual

4
FRONT WHEEL INSTALLATION
1. Orient the front tire so the arrow
on the tire faces forward.
2. Insert Axle bolt with the 14mm
washers between the forks and
wheel assembly on each side.
14mm Axle Bolt
14mm Washer
14mm Lock Nut
Arrow faces forward
Large 8mm Washers
14mm Axle bolt 1ea.
14mm washers 2ea.
14mm lock nut 1ea.
3. Install 14mm lock nut
4. Tighten Lock nut snug,
Note: Do not over
tighten Lock nut. Over
tightening can damage
wheel bearings.
