6
CONTROLS AND JACKS
1. Current clamp
2. Clamp Opening Trigger
3. Rotary Function Switch
4. LCD display
5. ZERO button
6. Data Hold and Backlight button
7. Mode select button
8. Range select button
9. Hz/% Duty Cycle button
10. COM input jack
11. V/Ω/Temp jack
12. Battery Cover (rear)
SYMBOLS AND ANNUNCIATORS
AC AC (alternating current)
DC DC (direct currrent)
Minus sign
AUTO AutoRange mode
ZERO ZERO mode
•))) Audible Continuity
HOLD Data Hold mode
Low Battery icon
Diode test mode M Mega
m milli Ω Ohms
V Volts °F Degrees Fahrenheit
A Amps °C Degrees Centigrade
