NOTICE:The ribs on the
shaft and the grooves in the
application tools permit a firm
connection of the aitiication
in increments of 30°, from 0_to
315° around the shaft (Fig. 41).
Allly the at tlication tool in the
orientation am_roeriate to the
task at hand.
USING THE FLUSH CUT
BLADE (Fig. 42)
1. Rnsertthe battery tack into
the multi-tool.
2. Ctaml theworkiiece securely.
3 Draw the cutting lines on
the work: i,iece_
4. Turn on the tool and allow
it to come to the full
desired smeed.
Fig. 41
Fig, 42
5, Cut the work tiece along
the line and a_ly with
aw _ro,ariate tressure until
the blade cuts to the de_th
needed according to the
scale on the blade.
NOTICE: The multi_,tool can also
be used with other Craftsman accessories (sold se narate!y} listed below:
MODEL DESCRIPTION
30753 MultiotOOIsanding _late for reilacement
17374 Sanding Pale_ (220, 280, 320 grit)
17375 Betait cut blade
17376 Rough cut btade
30858 Multi-tool Caulk Removal btade
31021 Diamond Coated Semicircle Saw Blade
31020 Circular Cutting Blade
3102 Stainless Steel Felt Polisher
31022 Finger Sanding Pad
31023 Finger Sanding Sheet Coarse
30566 I_a_uaLRe_ sed ']J O7!,.5 Page 28
,_ WARNING.'.To avoid serious _ersonal injup_*,always remove the battery
i_ackfrom the tool when cleaning or lerforming any maintenance.
_lk WAFINING: When servicing, use only identical reilacement i:ar[s. Use of any
other marts may create a hazard or cause iroduct damage.
,_ WARNING," _tis not recommended to use co,mtressed dry air as cleaning
method of the tool If cleaning with corn i,ressed air is the only method to a_ _ly,
always wear safety goggles or safety glasses with side shields when using
compressed air to clean the tool if the o_eration isdusty, also wear a dust mask.
GENERAL MAINTENANCE
Avoid using solvents when cleaning ilastic ma_s Most _lastics are suscettible
to damage from various tyles of commercial solvents and may be damaged by
their use. Use clean c:loths to remove dir_, dust, oil, grease, etc.
WAFIN|NG; Do not at any time _etbrake fluids, gasoline, petroBeumobased
|roducts0 |enetrating oils, etc. to come in contact with _lastic tarts. Chemicals
can damage° weaken or destroy _iastic which may result in serious
_ersonal ir_uryo
WARNING; When servicing, use only identic:al reilacement ia_s. Use of any
other _a_ts may create a hazard or cause _,roduct damage. To ensure safety and
reliability, all repairs should be performed by a qualified sewice technician.
BATTERIES:
The battery _ack is eoui_ed with Lithiumoion
rechargeable batteries The duration of u_ from each
charge will de _,endon the type of work i,erformedo
The batteries in this tool have been designed to
_rovide maximum trouble-free life. Like all batteries,
they will eventually wear out. Do not disassemble
the battery _ac:kor attempt to re_lace the batteries.
Handling of the batteries, es_,ecial_ when wearing
rings and jewelry, could result in a serious bum.
To obtain the longest _ossible battery life, read and
understand the o_erator's manual.
When not in use, it is good _,rac:ticeto un|lug the QuickBoost charger and to
remove the Lithium ion battery _ack f_om the tool.
For Lithium.Jon battery _ack storage longer than 30 days:
• Store the Lithium-Ion battery _ack where the tern _erature isbelow 80°F
(26°0} and Freeof moisture.
30566 ManuaLRe,,_sedoJ,_ 071,.5 Pa_e 29
