Creality CR-6 Max User Manual

Install the Pull Rod
安装拉杆
Adjust the proper length of assembled pull rod and install in the position shown in the figure
拉杆组装调节到合适的长度，安装在图示位置
3
14
14
8
8
15
15
11
11
14
M6 Union bolts ×4
M6 活接螺栓
M6 Hexagon nuts ×4
M6 内六角螺母
15
Pull rods｜拉杆
8
x 4
10
10
10
M5×12 Hexagon flat round
head screw x2
M5x12 内六角平圆头螺丝
13
13
M6 Screw bolt x2
M6 全螺纹螺栓
11
M5x20 Hexagon flat round
head screws x2
M5x20 内六角平圆头螺丝
