LUBRICATION/FILTERS/FRUIDS
96
Air Filter Element Removal
Avoid over servicing the air filter element. The filter element should be
removed for cleaning only when restriction causes a power loss.
Stop the engine
Lift the hood and connect the hood
support rod.
When servicing the air filter element,
remove clamp and remove element
by pulling it straight out very slowly
and carefully. Clean interior of canister.
After replacing the new or cleaned
element, install and tighten the
wing bolt.
NOTE: Never attempt to remove the
element from the air cleaner while the
engine is running.
When installing the element, inspect
the element gasket. If the gasket or
element surface is damaged, replace
the element immediately.
STEP 1
STEP 2
STEP 3
STEP 4
OUTER
INNER
CLAMP
ELEMENT
