INSTRUMENTS/CONTROLS
23
2. ENGINE SPEED CONTROL LEVER
Move the engine speed control lever
to the rear to increase engine speed.
Move the engine speed control lever
forward to decrease engine speed.
3. LAMP SWITCH Three position switch as follows:
ALL lamps are OFF. (Turn signal and
flasher lamps can be turned on.)
First position clockwise illuminates
instrument panel lamp and rear red
lamp.
Second position clockwise illuminates
headlamps, instrument panel and
rear red lamp.
Use dimmer switch to dim or brighten
the headlamps.
4. FLASHER CONTROL BUTTON
To flash the Flasher Lamps
whenever the tractor is operated or
traveling onroads.
Push the button to energize the lamps.
DECREASEDECREASE
LAMP
SWITCH
LAMP
SWITCH
ENGINE
CONTROL
LEVER
ENGINE
CONTROL
LEVER
INCREASE
INCREASE
