It may also be necessary to loosen the hex nut on the left 
idler pulley to get the belt off the pulley and around the
belt guard.
Carefully remove the deck belt from around the two 4.

To place the new belt, begin by routing the belt around the 5.
two outer spindle pulleys as shown in Fig. 7-7.
Then route the belt around the two deck idler pulleys as 6.
shown in Fig. 7-7.
Retighten the belt keeper rod loosened earlier.7.
Remount the belt guards removed earlier.8.
Reinstall the deck as follows:
With the deck beneath the mower frame, attach the a.

b.
c.

 
Cutting Blades
WARNING! 
ignition key before removing the cutting blade(s) for

using heavy gloves when grasping the blade
WARNING! 

struck a foreign object. Do not operate the machine
until damaged components are replaced.
To remove the blades, proceed as follows:
Remove the deck from beneath the tractor, (refer to 
Cutting Deck Removal earlier in this section) then gently
flip the deck over to expose its underside.
Figure 7-7
PTO Belt
Rotate
Pulley
Figure 7-8
26 se c t i O n 7— se r v i c e
