Model Series 400
Ref. Part Number Description
918-04815A Transmission Assembly
1. 919-04184A Housing, Transmission
2. 710-3008 Hex Screw, 5/16-18, .75, Gr5
3. 911- 0 4 8 4 4 Shaft, Tiller
4. 911- 04 85 4 Shaft, Wheel
5. 911-05028 Shaft, Worm
6. 714-04059 Key, Hi Pro .25 x 1.062
7. 716-0204 Retaining Ring
8. 716-04102 Retaining Ring, Int
9. 917-04380 Worm Gear, 61t, RH
10. 917-04381 Worm Gear, 30t, LH
11. 918-04435 Bearing Cover
12. 921-04030 Seal, Oil, .750 Shaft x 1.783 Bore
13. 921-04229 Gasket, Gear Housing
14. 721-04232 Seal, Oil, 1.00 Shaft x 2.00 Bore
15. 721-04271 Rubber Plug, Oil
16. 732- 0614 Wire Ring
17. 736-04305 Washer, Flat, 1.50 x 1.75 x .062
— 736-04306 Washer, Flat, 1.50 x 1.75 x .005
— 736-04307 Washer, Flat, 1.50 x 1.75 x .03
— 736-04308 Washer, Flat, 1.50 x 1.75 x .010
18. 736-0745 Washer, Flat, 1.010 x 1.56 x .060
19. 941-04298 Cone Bearing
20. 941-04299 Bearing Cup
21. 741-3114 Ball Bearing
22. 786-04366 Cover, Transmission
23. 786-04392 Cover, Transmission
* — The at washers listed are used as required to obtain .005 to
.015 in allowable end play on the drive shaft.
To Next Page
