56
270-V0 Fuel Tank
Ref. Part Number Description
1 710-04968 Bolt M6×16
83 951-11067 Throttle Control Knob
84 951-12131 Primer Bracket
85 710-04928 Bolt M6×12
86 951-11585 Governor Spring
87 951-10664 Throttle Linkage Spring
88 951-10665 Throttle Linkage
90 951-1110 6 Governor Arm Bracket
91 712-04212 Nut M6
92 710-04908 Governor Arm Bolt
93 951-10650 Fuel Line Kit
94 951-10650 Fuel Hose Clamp
Ref. Part Number Description
95 710- 04915 Bolt M6×12
96 951-11914 Dipstick Decoration Cover
97 710-04905 Bolt
98 710-04915 Bolt M6×12
100 951-11381 Oil Fill Tube O-Ring
101 951-11913 Oil Fill Tube Assembly (Incl. 100)
102 951-11904 Dipstick O-Ring
103 951-11912 Dipstick Assembly (Incl. 102)
104 951-10917A Fuel Cap Assembly
105 951-10653B Fuel Tank Assembly
106 951-11933 Fuel Filter
107 951-10651 Fuel Tank Nipple
103
102
101
100
97
104
106
105
107
93
94
94
95
90
91
92
86
87
88
83
84
1
85
85
96
97
98
To Next Page
