D-Link AC1900 User Manual

10D-Link DIR-878 User Manual
Section 3 - Installation
2. Position your DIR-878 near your Internet-connected modem. Place it in an open area for better wireless coverage.
1. The DIR-878 is designed to give you the fastest, most stable network connection possible. In order to maximize
performance, fully extend the antennas into a 115 degree angle to provide optimal wireless coverage. Keep the router
in an open area for better wireless coverage.
3. Turn o and unplug the power and Ethernet cable to your cable or DSL broadband modem. This is required. In some
cases, you may need to turn it o for up to ve minutes.
DIR-878
Modem
DIR-878
Modem
Hardware Setup
115°

D-Link AC1900 Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN (RJ-45) ports	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Input current	3 A
Rack mounting	No
USB ports quantity	2
DHCP client	-
Security algorithms	WPA, WPA2, WPS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-25 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Certification	FCC B\\r CE B\\r C-Tick\\r IPv6 \\r Wi Fi \\r (WPS)\\r (WMM)\\r Windows 8

Weight and Dimensions

Depth	190.4 mm
Width	246.9 mm
Height	47.2 mm
Weight	745 g
