D-Link AC750 Quick Install Guide

3
Hardware Overview
1 Power LED A solid green light indicates a proper connection to the power supply.
2 Internet LED A solid green light indicates a connection to the Internet port.
3 WPS LED
A solid green light indicates a successful connection using WPS. The light
will blink during the WPS process.
4 Wireless LED
A solid green light indicates the wireless function is working properly. This
light will blink during data transmission.
5 LAN LEDs (1-4)
A solid green light indicates a connection to a device is working properly.
The LED will blink during data transmission.
6 LAN Ports (1-4) Connect Ethernet devices such as computers, switches, and game consoles.
7 Internet Port Connect a broadband modem to this port using an Ethernet cable.
8 Power Port Connect the supplied power adapter.
9
WPS/Reset
Button
WPS - Press for one second to start the WPS process. The WPS LED will
blink during the process. The light will turn solid green when successfully
connecting to a device.
Reset - Press and hold the reset button for eight seconds to reset the router
back to the factory default settings.
1 432
6
5
7
8 9

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
