D-Link AC750 Quick Install Guide

4
• Users with DSL providers - If you are using a PPPoE connection, you will need
your PPPoE user name and password. If you do not have this information, contact
your Internet provider. Do not proceed until you have this information.
• Users with Cable providers - Make sure you unplug the power to your modem.
In some cases, you may need to turn it o for up to ve minutes.
• Advanced Users - If your ISP provided you with a modem/router combo, you will
need to set it to “bridge” mode so the DIR-813 router can work properly. Please
contact your ISP or refer to the user manual for your modem/router device.
Before you Start
1
Unplug the power to your DSL or Cable modem.
2
Connect an Ethernet cable from the Internet port of the router to the
Ethernet port on your DSL or Cable modem.
Modem
Connect your Router
1 2 3 4 INTERNET 5V --1A POWER
WPS
Ethernet Port
Modem
Ethernet Cable
DIR-813
Internet Port (yellow)

D-Link AC750 Specifications

Network Interfaces

LAN interface	Four 10/100Mbps LAN ports
WAN interface	One 10/100Mbps Internet port
Wireless interface (2.4Ghz)	IEEE 802.11b/g/n
Wireless interface (5Ghz)	IEEE 802.11a/n/ac

Operating Environment

Operating temperature	0 to 40 °C (32 to 104 °F)
Storage temperature	-20 to 65 °C (-4 to 149 °F)
Operating humidity	10% - 90% non-condensing

Wireless Specifications

Wireless frequency range (2.4Ghz)	2.412GHz ~ 2.483.5GHz
Wireless frequency range (5Ghz)	5.15GHz ~ 5.825GHz
Wireless bandwidth rate IEEE 802.11n	6.5 to 300 Mbps

Dimensions and Weight

Dimensions	156.5 x 113.2 x 53.6 mm (6.16 x 4.46 x 2.11 inches)
Weight	184.7 grams (0.41 lbs)
Antenna type	Internal Antenna
