D-Link DAP-2590 User Manual

DAP-2590 Install Guide 1
Minimum System Requirements:
• CD-ROM Drive
• Computers with Windows
®
, Macintosh
®
, or Linux-based operating
systems
• Installed Ethernet Adapter
• Internet Explorer version 7.0 or Firefox 3.0 and above
System Requirements
Package Contents
Note: Using a power supply with a different voltage than the one included with the
DAP-2590 will cause damage and void the warranty for this product.
If any of the above items are missing, please contact your reseller.
Hardware Overview
LEDs
DAP-2590
802.11n Access
Point
Power
Adapter
Ethernet
Cable
CD-ROMMounting
Plate
5 GHz - When lit, the access point is operating at
5GHz. This light will blink when there is wireless traffic.
2.4 GHz - When lit, the access point is operating at
2.4GHz. This light will blink when there is wireless
traffic.
LAN - Solid light when the Ethernet port is connected to a working port, such
as a router or switch. The light will blink when there is traffic through LAN port.
POWER - The light will blink during boot up. Once solid, the access point is
ready.

D-Link DAP-2590 Specifications

General

Maximum data transfer rate	300 Mbit/s
Frequency range	2400 - 2483.5 MHz
Connectivity LEDs	Yes
Compliance industry standards	IEEE Draft 2.0 802.11n/IEEE 802.11a/IEEE 802.11g/IEEE 802.3ab/IEEE 802.3af/IEEE 802.3u/IEEE 802.3
Internal	No
Power requirements	48V DC
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	762 g
Dimensions (WxDxH)	165 x 185 x 43 mm
