D-Link DAP-2660 Quick Installation Guide

D-Link DAP-2660 Quick Install Guide
1
ENGLISH
DAP-2660 Quick Install Guide
This installation guide provides basic instructions for installing the DAP-2660 Wireless Access
Point on your network. For additional information about how to use the Access Point, please
see the User’s Manual which is available on the CD included in this package or from the
D-Link support website.
System Requirements
Minimum System Requirements:
• CD-ROM Drive
• an Ethernet port, or an installed Ethernet adapter
• Internet Explorer 7.0, Safari 5.0, Firefox 3.5, Chrome 20 or later versions of these
browsers
1. Package Contents
 DAP-2660 802.11ac Power over Ethernet (PoE) Access Point
 Mounting Brackets
 Quick Start Guide
If any of the above items are missing, please contact your reseller.
NOTE no PSU supplied. To power the units use an D-Link PoE switch or the D-Link
DPE-101GI PoE injector.

D-Link DAP-2660 Specifications

General

2.4 GHz	Yes
Modulation	PSK
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	FCC\\r IC\\r CE\\r UL
Security features	Network access point (NAP)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	4 dBi
Power consumption (typical)	11 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	562.5 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	439460 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	239 mm
Shipping (inner) case length	352 mm
Shipping (inner) case weight	4385 g
Shipping (inner) case net weight	2230 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	316 g
