D-Link DAP-2660 Quick Installation Guide

D-Link DAP-2660 Quick Install Guide
3
ENGLISH
2. Connect the access point and your computer to the same switch. Manage the
access point from the computer.
Enter http://dap2660.local/ in the address field of your browser, which is the default
IP address of the access point.
Log in to the Administration Web pages. The default login information is:
Username: admin
Password: admin
Power on the access point
To power on the DAP-2660, you can use ONE of the following methods:
1. Plug one end of your Ethernet cable into the LAN port of the DAP-2660, and the
other end into a port on a PoE switch.
2. Purchase separately a DPE-101GI PoE injector if you need to connect the Access
Point without a PoE Switch.
Congure the access point
To set up and manage the DAP-2660, use one of the following methods:
1. Connect the access point and your computer via DPE-101GI. Manage the access
point from the computer.
Ensure your computer is congured with a static IP address in http://dap2660.local/
subnet.
Launch a web browser, type the default IP address of the access point ( http://
dap2660.local/ ) and then press Enter.
Log in to the Administration Web pages. The default login information is:
Username: admin
Password: admin
3. Installation
OR
Computer
PoE Switch
DAP-2660
Computer
PoE Injector
Power
Adapter

D-Link DAP-2660 Specifications

General

2.4 GHz	Yes
Modulation	PSK
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3u
Maximum data transfer rate	1200 Mbit/s
Internal	No
Certification	FCC\\r IC\\r CE\\r UL
Security features	Network access point (NAP)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, SSID, WPA, WPA2
Antenna features	Integrated antenna
Antennas quantity	4
Antenna gain level (max)	4 dBi
Power consumption (typical)	11 W
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	269 mm
Package width	204 mm
Package height	64 mm
Package weight	562.5 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	2047 mm
Pallet gross weight (air)	439460 g
Quantity per pallet (air)	480 pc(s)
Shipping (inner) case width	290 mm
Shipping (inner) case height	239 mm
Shipping (inner) case length	352 mm
Shipping (inner) case weight	4385 g
Shipping (inner) case net weight	2230 g
Number of cartons per pallet (air)	96 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	170 mm
Height	28 mm
Weight	316 g
