D-Link DES-1005D User Manual

i
TABLE OF CONTENTS
ABOUT THIS GUIDE..................................III
PURPOSE.......................................................... III
TERMS/USAGE .................................................. III
OVERVIEW OF THIS USER’S GUIDE.......................... III
INTRODUCTION .......................................... 1
FAST ETHERNET TECHNOLOGY................................1
SWITCHING TECHNOLOGY ......................................2
FEATURES ..........................................................3
UNPACKING AND SETUP........................... 5
UNPACKING........................................................5
SETUP...............................................................5
IDENTIFYING EXTERNAL COMPONENTS
........................................................................ 7
FRONT PANEL .....................................................7
REAR PANEL.......................................................7
LED INDICATORS ................................................8
CONNECTING THE SWITCH..................... 9
PC TO SWITCH ....................................................9
HUB TO SWITCH ................................................10
A. 10BASE-T Hub...........................................................................10
B. 100BASE-TX Hub.....................................................................10

D-Link DES-1005D Specifications

General

Forwarding rate	0.1488 Mpps
MAC address table	2000 entries
Store-and-forward	Yes
Packet buffer memory	0.046875 MB
Maximum data transfer rate	0.2 Gbit/s
Supported data transfer rates	10/20/100/200 Mb/s
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	100Base-TX, 10Base-T
Heat dissipation	8.528 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	2.5 W
Switch type	Unmanaged
Switch layer	-
Certification	RoHS, FCC, CE
Product color	Black
LED indicators	LAN, Power
Package depth	105 mm
Package width	65 mm
Package height	98 mm
Package weight	170 g
Cables included	AC
Packet transfer speed	14880 - 148800 p/s
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Basic switching RJ-45 Ethernet ports quantity	5
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1975 mm
Pallet gross weight (air)	465250 g
Quantity per pallet (air)	2400 pc(s)
Shipping (inner) case width	350 mm
Shipping (inner) case height	230 mm
Shipping (inner) case length	515 mm
Shipping (inner) case weight	9250 g
Shipping (inner) case net weight	8500 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	50 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	83.4 mm
Width	125.3 mm
Height	29.1 mm
