Figure 10 — Connecting a DGS-3630 Series Switch to the DPS-500A
Installing the RPS into a Rack-mount Chassis
DPS-800
The DPS-800 is a standard-size (1 standard unit in height) rack-mountable unit designed
to hold up to two RPS units.
NOTE: This rack-mount chassis supports the following RPS units: DPS-500A and
DPS-500DC.
Figure 11 — Install the DPS-500A in the DPS-800
7
