DSL-2640U Wireless ADSL2+ Router with Ethernet WAN Support
User Manual
Configuring via Web-based Interface
You can specify the following parameters:
Parameter Description
SSID
A wireless network to which the rule will be applied. Select the
needed value from the drop-down list.
MAC address
In the field, enter the MAC address to which the selected filtering
mode will be applied.
Hostname
The name of the device for easier identification. You can specify any
name.
Enable
If the switch is moved to the right, the rule is active.
Move the switch to the left to disable the rule.
When you have configured the parameters, click the SAVE button.
To edit the parameters of the existing rule, in the Filters section, left-click the needed rule. In the
opened window, change the settings and click the SAVE button.
To remove the rule from the page, in the Filters section, select the checkbox located to the left of
the relevant rule and click the DELETE button.
After creating the rules you need to configure the filtering modes.
To open the basic or additional wireless network for the devices which MAC addresses are
specified on this page and to close the wireless network for all other devices, left-click the line of
the wireless network. In the opened window, move the Enable MAC filter switch to the right.
Upon that the MAC filter restrict mode drop-down list will be displayed. Select the Allow value
from the drop-down list and click the SAVE button.
To close the wireless network for the devices which MAC addresses are specified on this page,
select the Deny value from the MAC filter restrict mode drop-down list and click the SAVE
button.
Page 120 of 174
