Daewoo B20S-2 User Manual

Power Train Disassembly & Assembly
5. Remove bolts (6), and remove spindle (7).
6. Remove shaft assembly (8).
7. Remove lip seal (9) from the housing.
8. Remove the retainer and bearing (10) from the
shaft.
Install Final Drives And Hubs
1. Install bearing (10) with a press. Heat the retainer
to 317 to 427°C (700 to 801°F) and install it
against bearing (10) with a press.
2. Install lip seal (9) in the housing with tool group
(B) and a suitable press. Install the seal with the
lip toward the inside.
Tools Needed A B
Spanner Wrench 1
Driver set 1
46
6
8
7
9
9
10
10
