20
Name of
Each Part
Front / Side Panel
The buttons on the TV set have the same functions as those of the remote control.
Control Key Buttons.
① TV/VIDEO Button : Each time you press this button, the TV will cycle through:
TV / AV1 / AV2 / AV3(S-Video) / COMP / PC / HDMI1 / HDMI2.
② MENU Button : Use this button to enter and exit the MENU.
③ ▲VOL▼Buttons : Use these buttons to change your TV’s volume or to move the cursor in the menu.
④ ▲PR▼ Buttons : Use these buttons to change channels on your TV or to move the cursor in the menu.
⑤ POWER ON button : Use this button to change from TV STANDBY mode to TV ON mode.
⑥LED Indicator : The led lights up red in STANDBY mode and Lights up blue in TV on mode. When TV is Child
Lock mode, LED will cycle through red / blue in STANDBY mode.
⑦ Remote control signal receiver
The screen contains the remote control signal receiving window. Therefore, point the remote control towards
the screen when using it.
