9
UP-GRADE
PORT
Antenna
Connection
Indoor Antenna Connection
Not recommended unless very close to the transmitter
Not recommended unless very close to the transmitter.
1. Connect the feeder cable of the antenna to the combining adapter.
WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of a wrong antenna
connection. Be sure to check its direction and site when installing.
2. Connect the combining adapter to the antenna input at the left side of the TV set.
WHEN USING THE COMBINING ADAPTOR : You may obtain the combining adapter at your nearest Service Cen-
tre.
Back of the tv set
Antenna Input
combining adapter
indoor aerial
To Next Page
