• Select [Component 1 or Component 2,
AV1(Scart), AV2(Scart) or AV3(S-Video)] by
pressing the “MULTIMEDIA” or “ ” button
of the remote control or the "INPUT SELECT"
in keypad of the PDP unit.
• Each time you press the “MULTIMEDIA”
or “ ” button, a different input mode
appears. The sequence is as follows:
Select the Desired Title and Function
• Select the desired title and function by
using the remote control of the DVD.
3
4
NOTES:
1) Y/Cb/Cr, which stands for component video DVD player’s
output can also be written as Y/B-Y/R-Y, Y/Pb/Pr depending on
the kinds of DVD model.
2) The way of connecting the DVD to the PDP is as follows:
Y <---> Y Cb <---> Pb, B-Y, Cr <---> Pr, R-Y
3) The DVD output can be Video, S-Video or Component Video
depending on the DVD model. There are various output
modes, so be sure to check when you purchase it.
4) When connecting S-Video and Video simultaneously, only S-
Video will be displayed on the screen as it takes precedence.
