Service Parts List
LOC PART CODE PART NAME PART DESCRIPTION REMARK
ZZ100 48B3740A01 TRANSMITTER R-40A01
REMOCON
ZZ110 PTACPWD216 ACCESSORY AS DTC-21V1TM
00100 4850Q00910 BATTERY R03/NN
00200 48586002E2 MANUAL INSTRUCTION ENGLISH,ARABIA
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHD344 COVER BACK AS DTC-21U1TM 21U1
M211 4852153401 COVER BACK HIPS BK 21U1
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV) 21U1
M591 4855930900 DECO TERM PVC CL T0.2 21U1
ZZ130 PTPKCPD344 PACKING AS DTC-21U1TM 21U1
M801 4858055200 BOX CARTON DW-3 21U1
M811 4858190500 PAD EPS 21U1 21U1
M821 4858211800 BAG P.E L.D.P.E T0.03X1300X1000 21U1
ZZ131 48519A5310 CRT GROUND NET 2101S-1015-1P 21"
ZZ131 48519A5110 CRT GROUND NET 2001S-1015-1P 20"
ZZ131 48519A4710 CRT GROUND NET 1401S-1015-1P 14"
ZZ132 58G0000074 COIL DEGAUSSING DC-2070 21"
ZZ132 58G0000086 COIL DEGAUSSING DC-2050 20"
ZZ132 58G0000084 COIL DEGAUSSING DC-1450 14"
ZZ140 PTCACAD344 CABINET AS DTC-21U1TM 21U1
M191 4851937302 BUTTON CTRL 4943001+5539201 21U1
M201A 4856013301 SCREW CRT FIXING 30X140 YL 21U1
M201B 4856215402 WASHER RUBBER CR T2.0 21U1
M201C 4856013303 SCREW CRT FIXING 30X250 YL 21U1
M211A 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 21U1
M211D 7172401412 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 21U1
M491 4854943003 BUTTON POWER ABS BK 21U1
M561 48556159SS MARK BRAND SILVER ETCHING 21U1
DIA-CUTTIN
M681 4856812001 TIE CABLE NYLON66 DA100 21U1
SP01A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN 21U1
SP02A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN 21U1
V901 4859625560 CRT A51EFK155X01 21"
CRT1 PTRTPWD217 CRT AS PAL 20" ITC CRT AS 20"
V01 58D0000083 COIL DY ODY-M2050
V02 48A96R004- RUBBER WEDGE HMR 28 SR (10X54)
V03 4850PM001- MAGNET CP NY-225 (MINI NECK)
V04 2TC26019BE TAPE CLOTH 19X30 BEIGE
V05 2224050026 BOND SILICON RTV 122 CARTRIDGE
V06 2233030001 PAINT LOCK 3B-1401B
V901 48A96420P4 CRT BARE A48JLL90X
CRT1 PTRTPWA605 CRT AS PAL 14" ITC CRT AS 14"
V01 58D0000082 COIL DY ODY-M1489
V02 48A96R004- RUBBER WEDGE HMR 28 SR (10X54)
V03 4850PM001- MAGNET CP NY-225 (MINI NECK)
V04 2TC26019BE TAPE CLOTH 19X30 BEIGE
V05 2224050026 BOND SILICON RTV 122 CARTRIDGE
V06 2233030001 PAINT LOCK 3B-1401B
V901 48A96414P4 CRT BARE A34JLL90X(K)
ZZ200 PTFMSJD344 MASK FRONT AS DTC-21U1TM
M201 4852071201 MASK FRONT HIPS BK 21U
ZZ210 PTSPPWD344 SPEAKER AS DTC-21U1TM
P601A 4850703S51 CONNECTOR YH025- 14U,21U
03+35098+ULW=300
P601A 4850703S50 CONNECTOR YH025- 14/20/21 V
03+35098+ULW=200
P601A 4850703S52 CONNECTOR YH025- 20U
03+35098+ULW=400
P602A 4850703S54 CONNECTOR YH025- 14U
03+35098+ULW=600
P602A 4850703S55 CONNECTOR YH025- 20U
03+35098+ULW=700
P602A 4850703S56 CONNECTOR YH025- 21U
03+35098+ULW=800
SP01 4858314010 SPEAKER SP-5070F01 3W 8 OHM
SP02 4858314010 SPEAKER SP-5070F01 3W 8 OHM Only U
ZZ290 PTMPMSD344 PCB MAIN MANUAL AS DTC-21U1TM
C101 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C102 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C103 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25)
TP
C301 CEXF1V471C C ELECTRO 35V RUS 470MF (10X20)
TP
C302 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C303 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20)
TP
C304 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP 21"
C304 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP 20"
C304 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP 14"
C305 CMXE2A473J C MYLAR 100V PU 0.047MF J
C306 CEXF1V101C C ELECTRO 35V RUS 100MF (8X11.5)
TP
C307 CMXM2A224J C MYLAR 100V 0.22MF J
C313 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C401 CMYE2D394J C MYLAR 200V PU 0.39MF J 21"
C401 CMYE2D434J C MYLAR 200V PU 0.43MF J 20"
C401 CMYE2D364J C MYLAR 200V PU 0.36MF J 14"
C402 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C404 CMYH3C722H C MYLAR 1.6KV BUP 7200PF H 21"
C404 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J 20"
C404 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J 14"
C405 CCXB3D271K C CERA 2KV B 270PF K (T) Only 21"
C406 CCXB2H102K C CERA 500V B 1000PF K
(TAPPING)
C410 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C411 CMYN1J105K C MYLAR (MKT) 63V 1MF K (7.5MM)
C420 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C421 CEXF2E330V C ELECTRO 250V RSS 33MF (13X25)
TP
C501 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C502 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
LOC PART CODE PART NAME PART DESCRIPTION REMARK
C503 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C504 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
C506 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
C507 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5)
TP
C511 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C512 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C513 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C514 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C515 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C516 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C520 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C522 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C523 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C524 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C601 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11)
TP
C602 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP
C605 CEXF1H108V C ELECTRO 50V RSS 0.1MF (5X11) TP Only U
C606 CEXF1C471V C ELECTRO 16V RSS 470MF
(10X12.5)TP
C607 CEXF1C471V C ELECTRO 16V RSS 470MF Only 21"
(10X12.5)TP
C611 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C620 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C701 CZSL1H470J C CERA 50V SL 47PF J (AXIAL)
C702 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C703 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C704 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25)
TP
C706 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C713 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C801 CL1JB3104M C LINE ACROSS AC250V 0.1MF M ECQ-UV
WRL
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C805 CEYN2G181P C ELECTRO 400V LHS 180MF (25X35)
C807 CMYU3C222J C MYLAR 1.6KV BCP 2200PF J
C809 CH1AFE222M C CERA AC 4KV 2200PF M KX DE1210
C814 CCYR3A471K C CERA 1KV R 470PF K 125 DE0705
C815 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25)
TP
C816 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C818 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25)
TP
C819 CEXF2A100C C ELECTRO RUS 100V 10MF 5*11
C820 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20)
TP
C821 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20)
TP
LOC PART CODE PART NAME PART DESCRIPTION REMARK
C822 CEXF1C101V C ELECTRO 16V RSS 100MF (6.3X11)
TP
C823 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C824 CCXB2H471K C CERA 500V B 470PF K (TAPPING)
C825 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C826 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C827 CEXF1C222V C ELECTRO 16V RSS 2200MF (13X25)
TP
C828 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20)
TP
C829 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C830 CEXF1C471V C ELECTRO 16V RSS 470MF
(10X12.5)TP
C841 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C842 CCXB3A102K C CERA 1KV B 1000PF K
(TAPPING)
C850 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C902 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C905 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C906 CBXB3D102K C CERA SEMI 2KV BL(N) 1000PF K (T)
CC102 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC103 HCQK121JCA C CHIP CERA 50V CH 120PF J 2012
CC104 HCQK121JCA C CHIP CERA 50V CH 120PF J 2012
CC105 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC108 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC109 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC110 HCQK240JCA C CHIP CERA 50V CH 24PF J 2012
CC118 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC412 HCQK160JCA C CHIP CERA 50V CH 16PF J 2012
CC501 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC504 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC505 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC506 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC508 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC509 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC510 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC511 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC512 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC514 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC515 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC516 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC517 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC518 HCBK222KCA C CHIP CERA 50V X7R 2200PF K 2012
CC519 HCFK334ZCA C CHIP CERA 50V Y5V 0.33MF Z 2012
CC520 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC521 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC522 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC523 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC524 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC526 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CC533 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
LOC PART CODE PART NAME PART DESCRIPTION REMARK
is safety component, so it must be used the same component.
is a recommendable part for stock.
®
®
®
®
®
®
®
®
