PANEL ASSY
NO PART CODE PART NAME Q'TY MATERIAL REMARKS
1 3611602801 DECORATOR 1 PET FILM 0.188T DWM-2520
3611604901 DWM-2530
2 3613400502 KNOB 3 ABS "DWM-2520,2530,2540"
450BA23002 "DWM-2500,2510"
3 7122401411 SCREW TAPPING 3 T2S TRS 4*14 MFZN
4 3610065010 PANEL 1 PP DWM-2530
3614209900 HIPS DWM-2540
3614202700 DWM-2520
3614200800 DWM-2510
3614201000 DWM-2500
5 3619900101 TIMER WASH 1 "SAN,S-K51A" "DWM-2530,2520,2510"
3619900110 "PC,S-K51C"
450BA47001 "SAN,S-K25A" "DWM-2500,2540"
45OBA47031 "PC,S-K25C"
6 7122401411 SCREW TAPPING 2 T2S TRS 4*14 MFZN
7 4509A07050 SPRING PLATE 1 -
8 3613700300 LEVERCONTROL 1 POM "DWM-2530,2520"
3613700900 "DWM-2510,2500,2540"
9 3617802000 LINK VALVE 1 "PP,620MM" "DWM-2500,2540"
3617802100 "PP,644MM" DWM-2510
3617802200 "PP,636MM" "DWM-2520,2530"
10 7341500811 TIMER SPIN 1 "SAN,S-2510A" "DWM-2530,2520,2510"
3619400901 "PC,S-251B"
3619400300 "SAN,S-2500A" "DW-2500,2540"
3616000703 "PC,S-2500B"
11 7122401411 SCREW TAPPING 2 T2S TRS 4*14 MFZN
✔ Caution :
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list.
So, if you need the latest parts information, please refer to PPL (Parts Price List) in Service Information Center
(http://svc.dwe.co.kr)
To Next Page
