INSTALLATION
■
LOCATION & ENVIRONMENT
Leave some space.
Space at least 10cm between the washer and the wall.
Place washer on a sturdy and flat surface.
If the washer is placed on an uneven or weak surface,
noise or vibration may be occurred.
(Allowable inclination is max. 2°)
Never install the washer near water.
Do not place the washer in steamy rooms or where the
washer is directly exposed to rain.
Moisture may destroy the electrical insulation and cause
an electric shock hazard.
Avoid direct sunlight or heating devices.
As plastic and electrical components are affected by direct
heat, never place the washer near heater, boilers, etc..
Do not place it under direct sunlight.
Avoid cold place.
Do not place or store the washer below 0°C(32°F) to avoid
any damage from freezing.
■
LEG SETTING
Slide the leg into the
opening underneath the base,
and push.
■
INLET HOSE SETTING
Attach the water inlet hose to the water inlet pipe.
■
DRAIN HOSE SETTING
! Connect the drain hose to the drain outlet at the rear
side of your washer.
@ The other end of drain hose setting toward the bath
or sinkhole.
# Install the drain hose under 85cm from the ground.
(In case DRAIN PUMP model)
CLEANING & MAINTENANCE
■
CLEANING THE DRAIN FILTER
In case of incomplete drain, remove lints from the drain
filter with soft brush.
■
CLEANING THE WASHER BODY
Wipe of stains on the cabinet and control panel with soft
cloth.
Do not use benzene, thinner, cleanser or wax.
(Plastic parts will be damaged.)
■
CLEANING THE OVERFLOW FILTER
Insert your finger into hole “A”
and then pull the overflow filter
in the direction of arrow as shown
in the figure.
■
CLEANING THE WASH TUB
Fill water in the wash tub to “L” level,
and operating wash cycle for
1~2 minutes.
After washing drain water from
the wash tub.
Close the wash tub lid.
Pr oper car e of your washer can extend its life.
