TROUBLE SHOOTING
PROBLEM CHECK POINT
Is the wiring of
Condenser properly
connected?
Improper wiring.
CAUSE SOLUTION
Reconnect.
Defective Wash timer. Replace Wash Timer.
NO
NO
YES
Is the wiring of wash
timer properly
connected?
Improper wiring.
Reconnect the Wash
Timer
NO
YES
PULSATOR
ROTATE ONLY
IN ONE
DIRECTION.
PROBLEM CHECK POINT CAUSE SOLUTION
Is the Condenser
properly
connected?
Motor does not start
due to opening the
Condenser circuit.
Reconnect.
NO
Is the Motor hot?
(In case there is
Thermal Protector)
Power has been cut off by
the Thermal Protector
Power restored when
Motor cools
YES
NO
Is the Wiring good? (Refer
to the Wiring Diagram)
Improper wiring. Reconnect the wiring.
NO
YES
Is there a whirring
sound form the Spin
Motor when turned ON?
NO
YES
THE SPIN
DRYER DOES
NOT ROTATE.
Are there strange noise
from Tub when the
Pulsator rotates?
Impurtities between
Pulsator and Tub.
Remove impurities after
disassembling Pulsator.
Pulsator improperly
assembled.
Tighten the Pulsator
fixing screw.
Something is in contact
with the Pulsator Pulley or
Motor Pulley or other
rotationg parts.
Adjust the parts so that
there are no impurities in
contact with rotating
parts.
YES
THERE IS
EXCESSIVE
NOISE
DURING
WASHING.
NO
Concerning Spin
YES
Is the contact of Spin
Timer good?
Defective Spin Timer Replace the Spin Timer.
NO
Defective Spin Motor
Replace the Spin Motor.
To Next Page
