16
PARTS DIAGRAM
NO. PART NAME PART CODE SPEC. Q'TY REMARKS
1 KNOB 3613403800 ABS 3.00
2 PANEL 3614280000 HIPS 1.00
3 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 2.00
4 BRACKET PANEL 3610607500 HIPS 1.00 HB, S/TIMER
3610607510 HIPS 1.00 HB, LEVER
3610607520 HIPS 1.00 VO, S/TIMER
5 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 3.00
6 TIMER WASH 3619910760 S-K60NT(MEXICO), SAN 1.00 S/TIMER
3619910770 S-K60NL, SAN 1.00 LEVER
7 LEVER CONTROL 3613701400 POM 2.00
8 SWITCH SELECTOR 3619045900 GSM-V1621A4 250V 16A 1.00 PUMP,S/TIMER
9 SWITCH SELECTOR 3619045700 GSM-V1623A4 2.00 LEVER
10 TIMER SPIN 3619910820 S-600FA(MEXICO) 1.00
11 SWITCH COVER 3619045400 GSM-V16183A4 250V 15A 1.00 OPTION
12 LINK VALVE 3617804700 PP, L2=718MM 1.00
7. PART LIST
PANEL ASS’Y
✔ Caution
:
In this Service Manual, some parts can be changed for improving, their performance without notice in the
parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
NO. PART NAME PART CODE SPEC. Q'TY REMARKS
1 COVER SAFETY 4506F61011 PE-LD 1.00
2 HOSE DRAIN O AS 3613224310 820MM,HANGER,NON CLAMP 1.00
3 HOSE DRAIN O AS 3613218800 LD-PE/EVA L=1600 PUMP 1.00
ACCESSORY ASS’Y
To Next Page
