PARTS DIAGRAM
NO. PART NAME PART CODE SPEC. Q'TY REMARKS
1 BOLT HEX(P) 7342602011 6B-2 6X20 POINTING MFZN 2.00
2 NUT HEX 7392600011 6N-2-6 MFZN 2.00
3 COUPLING DRUM 3619400300 AL 1.00
4 BOLT HEX 7341500811 6B-1 5X8 MFZN 3.00 OPTION
5 SPRING BRAKE LEVER 3615109000 SWC D1.0 ZN8-C 1.00 OPTION
6 PLATE BRAKE AS 3414517400 ASSY, 4.0KG 1.00 OPTION
7 ASSY BRAKE WIRE 3619201702 SUS WIRE+PE L260 1.00 OPTION
8 BELT V 3616500800 A36.6 1.00
9 NUT HEX 7392800011 M8X1.25 MFZN 1.00
10 SPECIAL WASHER 3616019100 PW-1-8.4 MFZN 1.00
11 PULLRY MOTOR AS 3618431600 PRESS(SGCC 1.2T,D24), 4.3MM 1.00
12 SPECIAL SCREW 3616017010 T2 TRS 4X35 MFZN PW 3.00
13 UNIT MOTOR WASH 3618946730 W1S35JD041, 127V/60HZ 1.00
14 CUSHION MOTOR 450M712020 NR 3.00
15 CUSHION SPOT 450M712010 PP 1.00
16 SCREW TAPPING 7122401611 T2S TRS 4X16 MFZN 3.00
17 MOTOR SPIN 3964720411 W1D25JE045 127V/60HZ 1.00
18 DAMPER 4509A14013 NBR, DW-3600 3.00
19 STOPPER UPPER 4509A14021 PP 3.00
20 SPRING CUSHION 4509A14031 SWC ZN8-C 3.00
21 STOPPER LOWER 3615200200 PP 3.00
22 C0VER BACK 3611400700 PP 1.00
23 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 1.00
24 HOSE PUMP 3613220900 LDPE(PLASET PUMP) 1.00
25 UNIT DRAIN PUMP 3618952500 110V 60HZ 30EN011 #1806 1.00
26 UNIT CAPACITOR 3618943210 41.6/16ßfi, 200/250VAC, E 1.00
27 BASE 3610391500 PP 1.00
28 CORD POWER WAK42H762- A VCTFK 2X0.75 2.3M GY 1.00
29 HARNESS OUTER 3612756110 L2850, GN, RING-TERMINAL 1.00
30 LEG 3617702400 PP 4.00
BASE ASS’Y
