TROUBLESHOOTING
2. SYSTEM CIRCUIT
No LED display.
Is 5V obtained at IC701
pin # 9, 25?
Oscillation at IC701 pin #1?
Check L703, pin#6 of PJ701
Exchange IC701.
Check IC 701 pin #6, 7, 8
Check IC 701 pin #
10-12,14,15
NO
YES
YES
NO
Check PCB
NO
NO
KEY output at PORT of IC701?
Is there KEY/SEG signal?
YES
SEG output at PORT of IC701?
Exchange IC701.
YES
A. LED DISPLAY
NO
