LOC PART CODE PART NAME PART DESCRIPTION REMARK
01 PVACPSN731 ACCESSROY AS DC-B8CB1N-PS(N619,AAA
DP01 97P95600N0 MANUAL OWERNS NTSC MODEL
DP02 97P880RN15 CABLE RF NTSC 1.5M
DP03 97P0424100 COVER ACCESSORY LD-PE T0.05
DP04 486A716202 BATTERY AAA 1.5V(SUPERGARD)
DP08 97P880P815 CABLE RCA 3P-3P WEL-WHT-RED 1.5M
02 PVPKCPN786 PACKING AS DW-Q73D2N-LS(YW,ST)
CP01 97P4936100 PAD R/L EPS(362X95X100)
CP02 97P4809200 POLY BAG FOR SET 800X650XTO.5 PE-FOAM
CP03 97P5060400 CARTON BOX 470X365X97(SW-4)
CP04 47P4502205 LABEL SERIAL A PAPER (42X12X1EA)
03 PVMCASN786 CHASSIS MAIN AS DW-Q73D2N-LS
A001 97P0487800 COVER BOTTOM SECC T0.8
A0011 97Q0804300 LEG EVA T=2.0 (¡¸14.5 )
A040 97P0487900 COVER TOP SECC T0.5+PAINT
A041 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
A050 97P0488000 COVER BACK SECC T0.8
A051 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
AG01A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
AJ01A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
AL01A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
AM01A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
AP01A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
D100 97P1RA2GA0 REMOCON HANDSET AS VR-FA2
M01 97PP349010 PANEL FRONT DW-Q73D2N-LS
B010 97P3043800 SPRING DVD DOOR SWPB
M200 97LA0064D- DECK TOTAL DVDR AS DDM-8100
PF04A 97P88F013S CABLE FFC 0.5 R 50P 220MM
NB09 97P88F014S CABLE FFC 1.0 S1 5P 120MM F1
NB12 97LA210200 TRAVERSE SONY AS DDM-8000
M200A 7173300611 SCREW TAPPTITE TT2 BIN 3X6 MFZN
P201A 97P88F011S CABLE FFC 1.0 K 25P 60MM
P603A 97P88F010S CABLE FFC 1.0 K 5P 60MM
P702A 97P88F012S CABLE FFC 1.0 K 5P 170MM
PW01 97P69BY910 CORD POWER USA LP-11W YH396 1.7M
Z001 PVMPMSN786 PCB MAIN MANUAL AS DW-Q73D2N-LS
JK101 97P6318250 JACK PIN DPAM-0257
JK201 97P6318130 JACK PIN DPAM-0219
JK203 97P6318010 JACK PIN(S-VHS) DUAE-9812
P101 97P62A23B6 CONN WAFER 440054-6 ST PLUG 6P
P201 97P62G08ER CONN FFC GF102-25S-TS 25P ST
P603 97P62G08E5 CONN FFC GF102-05S-TS 05P ST
PJ601 97P885X252 CONN AS 7H-7S 110MM
RF101 97P7622900 TUNER 3 IN 1 LGTMI-US7H
X601 5XJ14R31AE CRYSTAL QUARTZ HC-49/S 14.31818MHZ 30PPM
Z0011 PVMPJ1N786 MAIN CHIP MOUNT BT AS DW-Q73D2N-LS
C102 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C103 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C108 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C114 HCQK809DBA C CHIP CERA 50V CH 8PF D 1608
C116 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C124 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C133 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
LOC PART CODE PART NAME PART DESCRIPTION REMARK
C137 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C140 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C150 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C152 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C153 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C154 HCBK223KBA C CHIP CERA 50V X7R 0.022MF K 1608
C156 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C158 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C161 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C202 HCQK471JBA C CHIP CERA 50V CH 470PF J 1608
C203 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
C206 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
C207 HCQK471JBA C CHIP CERA 50V CH 470PF J 1608
C213 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C225 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C226 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C227 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C230 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C602 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C603 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
C604 HCQK150JBA C CHIP CERA 50V CH 15PF J 1608
C605 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C606 HCQK471JBA C CHIP CERA 50V CH 470PF J 1608
C607 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C609 HCQK201JBA C CHIP CERA 50V CH 200PF J 1608
C610 HCQK102JBA C CHIP CERA 50V CH 1000PF J 1608
C611 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C612 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C614 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
C615 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
C617 HCFH104ZBA C CHIP CERA 25V Y5V 0.1MF Z 1608
IC101 1CD4052BMD IC CHIP LOGIC CD4052BM SOIC 16 REEL
IC102 1CD4051BMD IC CHIP LOGIC CD4051BM SOIC 16 REEL
IC103 1LA72702VQ IC CHIP STEREO DECODER LA72702VA SSOP24 TRAY
IC104 1LA7213 - IC LA7213
IC201 1NJM4580MC IC CHIP AMP NJM4580M
IC601 168K37760H IC MICOM M37760EFHGP
L101 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L102 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L103 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L105 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L106 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L108 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L201 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L202 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L203 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L601 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
L602 HLB600M06A L CHIP BEAD 60 OHM MPZ 1608
R101 HRFS750JBA R CHIP 1/16 75 OHM J 1608
R103 HRFS243JBA R CHIP 1/16 24K OHM J 1608
R104 HRFS102JBA R CHIP 1/16 1K OHM J 1608
R105 HRFS102JBA R CHIP 1/16 1K OHM J 1608
R106 HRFS102JBA R CHIP 1/16 1K OHM J 1608
ELECTRICAL PARTSLIST
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts
information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
1. POWER
