23
Dimension (mm)
Maximum mass of textile (kg)
Unit Weight (kg)
Standard Water Consumption
Spin Speed (RPM)
Operating Water Pressure
595 x 540 x 850 (W x D x H)
7.0
58(Net) / 62(Gross)
52"
400/800/1000/1400
0.03MPa ~ 0.8MPa (0.3kgf/cm
2
~ 8kgf/cm
2
)
MODEL DWD-FD1411
SPECIFICATION
WIRING DIAGRAM
Downloaded From WashingMachine-Manual.com Manuals
