6. FUNCTIONS OF THE CONTROL PANEL
FUNCTIONS OF THE CONTROL PANEL
■ D-M805'S/M105'S
Program selector
For switching the washing machine on and off
and for selecting the program.
Can be rotated in both direction.
Even if the program selector rotates while the
program is running, the program is not changed
(except for off ) .
(All program is electronically controlled by PCB)
Indicator light
The respective indicator lights up, when the
required program segment runs or ‘Time
delay’ is selected.
Time delay
To pre-engage time for washing.
As the button is pressed, the delayed time is
repeated as following;
2hours ➝ 3hours ➝ 4hours ➝ • • •
➝ 46hours ➝ 47hours ➝ max 48hours
Spin selector
You can select the spin programs (Spin
800rpm(1000rpm)
and Spin 500rpm) by turning the Program
selector.
500rpm of spin velocity is selected
automatically with WOOL/Hand Wash program
in order to protect damage on laundry.
800rpm(1000rpm) of spin velocity is selected
automatically with
COTTON/SYNTHETIC/Quick15'/Intensive/
Sportswear/Rinse+Spin programs.
*Warning
If value of unbalance is extremely high, spin
speed can't reached that r.p.m of selected by
spin selector.
Start/Hold button
For starting the washing cycle.
(program must have been selected)
Button for options
(in addition to the program if required)
Rinse + Extra rinse cycle.
Rinse Hold No final spin cycle.
• Combination of additional option is possible.
• The indicator lamp of the buttons lights up if
options are active.
• Switch off option : Press button again.
Note
By turning right the Program Selector, the program is selected in order of
COTTON COLD ➝ COTTON 40° ➝ COTTON 60° ➝ COTTON 60°/Pre ➝ COTTON 95° ➝
SYNTHETIC ➝ WOOL/Hand Wash ➝ Quick 15' ➝ Intensive ➝ Sportswear ➝ Rinse+Spin ➝
Rinse ➝ Spin 500rpm ➝ Spin 800rpm(1000rpm) ➝ Drain ➝ OFF ➝ COTTON COLD ➝ COTTON
40° ➝ •••
