THE REPAIR
①Separate the back cover from
washing machine.
④Turn the case filter ass’y and sepa-
rate it from the drain motor.
⑦Assemble the case filter ass’y that
purchased.
⑩Assemble the hose drain I to the
case filter with bond & clamp.
②Remove two screws.
⑤Separate the drain hose I from the
case filter ass’y.
⑧Tie up three screws.
⑪Assemble the cavitation hose to
the case filter with bond & clamp.
③Remove three screws.
⑥Separate the cavitation hose from
the case filter ass’y.
⑨Tie up two screws.
⑫Assemble the back cover to the
washing machine.
REPLACE THE CASE FILTER ASS’Y
